Durch den Einsatz der 182-mm-Multi-Gate-(MBB) monokristallinen Half-Cut-PERC-Zellentechnologie für Hochleistungssolarzellen werden die BOS-Kosten des Systems durch eine höhere Komponentenleistung effektiv gesenkt
Elektrische Parameter bei STC | ||||||||||||||||
Modultyp | MSD580P | MSD585P | MSD590P | MSD595P | MSD600P | |||||||||||
Bewerten Sie die maximale Leistung (Pmax/W) | 580 | 585 | 590 | 595 | 600 | |||||||||||
Moduleffizienz (%) | 20.70 | 20,90 | 20.10 | 21.30 | 21.50 | |||||||||||
Leerlaufspannung (Voc/V) | 53,50 | 53,65 | 53,80 | 53,95 | 54.10 | |||||||||||
Kurzschlussstrom (lsc/A) | 13.82 | 13.89 | 13.96 | 14 03 | 14.10 | |||||||||||
Spannung bei Pmax(Vmp/V) | 44,90 | 45.07 | 45.22 | 45,39 | 45,53 | |||||||||||
Strom bei Pmax(lmp/A) | 12.92 | 12,98 | 13.05 | 1311 | 13.18 | |||||||||||
Machttoleranz | o-+5w | |||||||||||||||
Temperaturkoeffizient von lsc | +0,046 %°C | |||||||||||||||
Temperaturkoeffizient von Voc | -0,276 %°C | |||||||||||||||
Temperaturkoeffizient von Pmax | -0,350 % °C | |||||||||||||||
STC | Bestrahlungsstärke 1000 W/m Zelltemperatur 25 °C AM1,5 | |||||||||||||||
Hinweis: Die elektrischen Daten in diesem Katalog beziehen sich nicht auf ein einzelnes Modul und sind nicht Bestandteil des Angebots. Es dient lediglich dem Vergleich verschiedener Modultypen |
About FGET
Future Green Techonology is committed to creating a green future.
Rooting ourselves in the new energy industry for decade, we manufacturehigh quality solar panel and battery and win high reputation from hundredscustomers globally.
We also have over 100 long-term partners around the world. We sell high-quality batteries and solar panels, and also customize solar panel systems and solar power stations for our customers who need them. If you also want to customize a solar panel system, you can submit your daily electricity consumption requirements below, and we will immediately develop a detailed energy solution for you.
Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.
