China Manufacturer Half Cut 120 Cells 400W 430W 440W 455W Solar Mono Panels

China Manufacturer Half Cut 120 Cells 400W 430W 440W 455W Solar Mono Panels

Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut PERC Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs

  •  Item No: MSD450M
  •  Cells Number: 120 Pcs
  •  Min Order: 10 PCS
  •  Voltage: 41.4V
  •  Module Efficiency(%): 21.1%
  •  Dimemsions: 1909*1134*35MM
  •  Weight: 23.9KG
  •  Packing Number: 31Pcs/Pallet
  •  Packing Volume: 2.834CBM/Pallent
  •  40'HQ Container: 744PCS
China Manufacturer Half Cut 120 Cells 400W 430W 440W 455W Solar Mono Panels
Advantages:
1. 120 Monocrystalline Half-Cut PERC Cells 182 x 91 MM, Higher Efficiency
2. Customizable All Black Design, Nice Appearance, Reduce Light Pollution
3. Junction Box Certified According To IEC 62790, IP 68 Approved, 3 Bypass Diodes
4. Glass High Transmission, Low Iron, Tempered, ARC, Transparent, 3.2 MM
5. Solar Cells: Mono
6. No. Of Cells: 120(6x20)
7. Mechanical Load Test: 5400Pa
8. Front Glass: 3.2MM Coated Tempered Glass
9. Frame: Anodized Aluminium Alloy
10. Junction Box: Ip68 Rated (3 By Pass Diodes)
11. Output Cables: 4.0MM 2, 300MM (+) / 400MM (-), Length Can Be Customized.
12. Connectors: MC4 Compa
Electrical Parameters at STC
Module Type MSD430P MSD435P MSD440P MSD445P MSD450P MSD455P
Rate Maximum Power(Pmax/W) 430 435 440 445 450 455
Module Efficiency(%) 19.90 20.10 20.30 20.60 20.80 21.10
Open Circuit Volatge(Voc/V) 40.65 40.80 40 95 41.10 4125 4140
Short Circuit Current(lsc/A) 13.59 13.67 1374 1382 13.89 13 97
Voltage at Pmax(Vmp/V) 33.89 30.09 34.28 34.48 34.67 34.87
Current at Pmax(lmp/A) 12.69 12.77 12 84 12 91 12.98 1305
Power Tolerance o-+5w
Temperature Coefficent of lsc +0.046%°C
Temperature Coefficent of Voc -0.276%°C
Temperature Coefficent of Pmax -0.350%°C
STC Irradiance 1000W/m Cell Temperature 25°C AM1.5
Remark: Electrical data in this catalogue does not refer to a single module, and it's not part of the offer. It only serves for the comparison among different module types
China Manufacturer Half Cut 120 Cells 400W 430W 440W 455W Solar Mono Panels


Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
good quality solar panels
Packaging process:
Solar Panel Corner Protection→Independent Cardboard Box Packaging→Pallet→Wooden Box→PET Plastic Steel Packaging Belt→PE Winding Film
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels

Product Size: 1909*1134*35mm

Package: 31pcs/Pallet: 24Pallets/40HQ

About FGET



Future Green Techonology is committed to creating a green future.

Rooting ourselves in the new energy industry for decade, we manufacturehigh quality solar panel and battery and win high reputation from hundredscustomers globally.

We also have over 100 long-term partners around the world. We sell high-quality batteries and solar panels, and also customize solar panel systems and solar power stations for our customers who need them. If you also want to customize a solar panel system, you can submit your daily electricity consumption requirements below, and we will immediately develop a detailed energy solution for you.

Support Factory About Future Green



Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.


Q2: What's the difference between Mono and Poly panels?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon. The process used to make polycrystalline silicon is simpler a
nd costs less. The amount of waste silicon is less compared to monocrystalline.

Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.

Q4: What is the warranty for solar panels?
A4: 5 years warranty on FGET-Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem solve easily.
